Applications
Access / Attendance
Basic
- Operating Temp. -15 to 55°C
- Humidity RH 5 to 95% Non-Condensing
- Weight 295 grams
- Dimensions (mm) H 207 x W 40 x D 42
- Supply Requirement Regulated 12V DC/2A
- Power 3.5 watt max.
Outside
- RTC Non volatile real time clock calendar, Data retention for 10 years without external power
- Display 1.77” Color TFT
- Audio Inbuilt piezo buzzer
- Camera Inbuilt VGA camera to capture snaps on specific events
- Enclosure IP65 rated weatherproof ABS-PC housing with sleek aesthetics
Inside
- CPU 32 bit Microcontroller running at 200 MHz
- Memory 16 GB Data flash, 2MB RAM
- Finger Print Module 1 GHz , 32 bit, Dedicated DSP processor with 256 bit AES fingerprint data encryption
- Finger Print Sensor Most rugged and accurate optical fingerprint sensor
- Door Sensor Optically isolated input for one door sensor
- Tamper Detect 3 axis accelerometer for tamper detection
- Watchdog Inbuilt watchdog supervisor
Capabilities
- Template Storage 25,00,000 fingerprint template storage for 1:1 match ( 25,000 Templates for 1:N match )
- Database 250,000 user database, support of upto 10 fingerprint templates per user
- Transactions 500,000 Time stamped events storage capacity
Credentials
- Resolution Fingerprint scanner with 500 dpi resolution
- EER <0.1%
- Verification Time 1:1 match < 0.3 sec, 1:N match < 0.4 sec for less than 1,000 fingerprint templates
- Authentication Mode Configurable mode : Only Finger, Only card, Card + Finger
-
Card Reader Support
Inbulit EM reader** (optional Mifare† , *HID® Proximity™, *HID® iCLASS®) for 1:1 match
**EM Proximity™ - 125KHz (4100, 4102, 4200) and *HID® Proximity™ - 125KHz
†Mifare - 13.56MHz (Mifare 1K/4K, DesFire, DesFire EV1) and iCLASS® - 13.56MHz
*Disclaimer: HID® Proximity™, HID® iCLASS® are trademarks or registered trademarks of HID Global Corporation. All trademarks, logos, and brand names are the property of their respective owners and are used here solely to indicate the use of genuine embedded modules for compatibility purposes.
Communication
- WiFi Inbuilt WiFi 802.11 b/g/n, Encryption : WEP Security : WPA/WPA2-Personal
- Bluetooth Mobile access support over bluetooth Smart (v4.2)
- Communication 10/100 Base-T RJ45 ethernet interface
Interface
- Protocols Supports TCP/IP IPv4 & IPv6, FTP, HTTP, NTP, SNMP & SSL
- Reader Interface Weigand configurable from 26 to 255 bits/Clock Data
- Lock Interface One potential free changeover relay, contact rating 3A/30VDC
- Aux Reader Port One weigand port is available can be used as weigand IN or weigand OUT, configurable.
- Digital Inputs Optically isolated one input for exit switch & two general purpose input (GPI)
- Digital Outputs One general purpose output (GPO) TTL level
